Don't Just Fill Your Tracks, TILL Them
Unique to the industry, the Orthman Track TILLr tills out the pivot track side walls with 22” cutting coulters and redistributes the soil that was pushed out, making for a solid foundation.
With an overall wider working width and a heavier frame design, the Track TILLr is effective at tilling out the sidewall of the pivot track and re-conditioning the track with soil rather than just residue.
The adjustable disc gangs and dual basket conditioners fine-tune the pivot track back to field level for a smooth pass with the next tillage or planting operation.
The Track TILLr 500 is proven to level soil nearly three times flatter than conventional track fillers with standard rolling levelers.
The front-mounted, width and depth-adjustable guide wheel centers the machine in the pivot track to accurately control the tillage depth. The recessed bearing design reduces residue wrapping and protects the four heavy-duty bearings for years of reliability.
The targeted tillage process begins with a pair of massive 22" notched disc blades that break up the toughest sidewall compaction and fill the bottom of the track rut with more soil and less residue than traditional track fillers. The width-adjustable discs are mounted on large tapered roller bearings to ensure season after season of trouble-free service.
The centered-mounted 10"-wide packer wheel features cleated drive lugs to propel it through the toughest soils. To optimize the firmness of the soil, the packer features 4 1/2" of height adjustment along with up to 1,500 pounds of down pressure adjustability.
Tool-free angle-adjustable disc gangs with concave blades that decreases in diameter from 22" down to 16" on the outside to feather the soil and residue out to 100" wide for a smooth finish.
Standard spring-cushioned dual rolling baskets with angled blades provide added soil leveling for a planter-ready finish. Down pressure is easily adjusted to provide ideal leveling from field to field and match soil conditions.
Make our Track TILLr your own to ensure it suits your operation's needs.
On-the-go hydraulic down pressure adjustability of the rolling baskets can be added for easier use.
Customize your Track TILLr with disc blade scrapers for wet, compacted soils.
Width | 8’6”Track TILLr |
|---|---|
| Hitch | CAT 3/3NCAT 2 Quick |
| Frame | Rigid |
| Disc Gang Blades Per Side(Inner to Outer) | 22”, 18”, 18”, 18” 16”, 16” |
| Trans. Width | 8' 8" |
| Trans.Height | N/A |
| Work Width | 8'6" |
| Trans. Length | 10' |
| Approx. Weight | 2,750 lbs |
| Min H.P. | - |
| Due to continuing improvements in the design and manufacture of Orthman products, all specifications contained herein are subject to change without notice. | |
